KELLYS E-CRISTY RS40 P - The versatile low-entry e-SUV for city and weekend trips

Featuring a Panasonic GXM 100 Nm motor and 725 Wh battery, it handles a range of routes with assistance and offers a comfortable entry-seat for a wider range of users. The sturdy frame, 29″ wheels and good equipment make the model an ideal choice for those looking for a reliable e-bike with good equipment and a compromise between performance and comfort.

Main specs: 100 Nm motor, 725 Wh battery, 29″ wheels, 1×9 gears, hydraulic disc brakes, X1 Air 120 mm air fork, full equipment for everyday use.

• Panasonic GXM mid-motor with approx. 100 Nm of torque.
• KELLYS K2 MAXXPRO CARBON battery with 725 Wh capacity, energy density ~213 Wh/kg.
• 6061-T6 aluminium alloy frame, made in Europe by robotic welding, with low-step for easier mounting.
• 29″ wheels,
• 1×9 gears (Shimano Cues U4000 kit) including hydraulic disc brakes (Shimano MT200 + Galfer 180mm discs) for good stopping power.
• SR SUNTOUR X1 Air fork with approx. 120 mm travel (some sources say 120 mm) = comfort and light terrain.
• Equipment for normal use: mudguards, rack, stand, LED lighting (Trelock), making it a versatile e-bike for trips and commuting.
• Manufacturer's estimated range of approx. 120 - 150 km (depending on settings, terrain, assistance).

While the components are solid, compared to a high-end e-MTB, the system may be designed for general purpose use (trekking/cross) rather than extreme off-road. If you are going to ride very hard off-road or have high lightness/weight requirements, it's a good idea to compare other alternatives.

KELLYS BICYCLES s.r.o. now offers an extended warranty of 5 years. This extended warranty covers the frame of the e-bike and its claim when a manufacturing or material defect is proven to be the cause.

E-bike range calculator

Battery capacity: 500 Wh

300 Wh 600 Wh 900 Wh 1200 Wh

Rider weight: 75 kg

50 kg 80 kg 110 kg 140 kg

Assistance mode: 3

Min 2 3 4 Max

Route profile: Flat

Flat

Medium

Hills

The e-bike range is approximately

*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique

Motor Panasonic GXM MAXXPRO

MAXXPRO – a revolutionary new e-bike drive system. Designed to deliver full power without unnecessary weight. The GXM MAXXPRO motor, developed jointly by Kellys and Panasonic, has a torque of 105 Nm and weighs just 2.56 kg, with a special magnesium alloy casing. Optimized cooling and mounting. The combined motor and battery system weighs approximately 6.1 kg. Modular and modern electronics: Open architecture, over-the-air (OTA) update capability, and compatibility with various batteries via CAN bus (open system).

More information

Battery Kellys Maxxpro 725 Wh

Kellys, in cooperation with German battery manufacturer BMZ, presents a new series of batteries called Maxxpro, which excel in high energy density. Energy density is the amount of energy stored in a given amount of material, measured in Wh/kg. Carbon batteries are up to 20% lighter and offer higher capacity. The batteries weigh approximately 3.5 kg. To achieve low weight and high energy density, Kellys used an all-carbon battery body.

More information

Designing and manufacturing e-bikes is not just about putting mechanical components together. It's more than that. The purpose for which an e-bike is created is important, because it has a unique purpose in each person's life. This mission gives every KELLYS e-bike its reason for being. Thanks to modern technology, skilled designers and the best materials, the Kellys brand has some of the highest quality e-bikes.

We are specialists in KELLYS electric bikes. We offer full suspension and fixed mountain bikes, touring bikes, men's and women's electric bikes with an excellent price / performance ratio.
