CORRATEC E-Power RS 160 Elite 800
The Corratec E-Power RS 160 Elite 800 is an all-suspension e-bike for demanding riders looking for performance, precise handling and confidence on any terrain. The combination of a 5th generation Bosch Performance Line CX motor, 800 Wh battery and RockShox premium suspension makes this e-bike the ideal partner for long rides, steep climbs and technical descents.
BK31428
Need help?
BOSCH Performance Line CX 5th gen.
85 Nm (up to 100 Nm)
800 Wh
12 speeds
27,5"/29"
160 mm
Dropper post Kind Shock 900i
The Kind Shock 900i dropper post allows you to quickly change saddle height for better control on technical terrain and increased riding comfort.
Optional ICR (Internal Cable Routing)
Indicates the internal cable routing system in the wheel frame. This design allows brake hoses, shift cables and electronic cables to be routed inside the frame, either through the head tube for a clean look or through holes in the down tube for more convenient maintenance.
The CORRATEC E-Power RS 160 Elite 800 is an e-bike made for true trail adventures. It combines power, precision handling and advanced technology to tackle steep climbs and challenging descents. The aluminium frame with its sophisticated geometry and full suspension system ensures stability, comfort and control on any terrain.
At the heart of the bike is the Bosch Performance Line CX 5th Gen motor with up to 100 Nm of torque (adjustable via the Flow app), powered by an integrated Bosch PowerTube 800 Wh battery.
Suspension is provided by a RockShox Psylo Silver RC 29" fork with 160 mm travel and a RockShox Deluxe Select+ RT rear shock, which guarantees confidence in technical passages and comfort on longer rides. Tektro HD M535 four-piston brakes with 203mm discs provide reliable stopping power in all conditions.
Power is provided by a 12-speed SRAM SX Eagle cassette with 11-50 teeth, offering a wide range of gears for every trail profile. Mullet combination wheels (29" front, 27.5" rear) shod in Continental Kryptotal tyres deliver the ideal mix of stability and agility.
Comfort is enhanced by the Kindshock 900i telescopic seatpost, Selle Italia X3 XP BOOST Superflow sport saddle and durable aluminium components. With a load capacity of up to 140 kg and a bike weight of 26.5 kg, the RS 160 Elite 800 is a robust yet playful partner for demanding riders.
The CORRATEC E-Power RS 160 Elite 800 is more than just an e-bike - it's a trail marvel that offers performance, precise handling and endless fun on any terrain.
Need help choosing the right e-bike? Use our guide to choosing an e-bike, or contact us directly.
E-bike range calculator
The e-bike range is approximately
*Factors affecting total range include assist mode settings, technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
This e-bike model supports connection to Apple's Find My service. This innovative feature allows users to track the location of their e-bike very accurately using the Find My app on their Apple devices. Apple's Find My network allows you to securely track your e-bike through a wide range of Apple devices. The bike's location is anonymised and encrypted so only the owner has access to it. This ensures a high level of security. The tracker is cleverly integrated into the motor housing of the e-bike and can be supplied with power through the normal charging process. It also has its own rechargeable battery that allows it to operate for up to a year without recharging. Thanks to the Apple network and therefore connecting to nearby devices, the e-bike can then be tracked even in places where there is no signal.
Bosch Performance Line CX 5th generation engine
The 5th generation motor offers 85 Nm and a peak power of 600 W. Thanks to the magnesium housing, it is lighter (2.8 kg) and quieter. The new mounting system makes installation easier. Improved sensors measure rider inputs more accurately, ensuring a more natural power transfer. The motor has hill-start and walk assist for added comfort. Lower weight improves maneuverability and component durability. Auto mode automatically adjusts terrain assistance. Compatibility with Bosch smart systems allows tracking of ride details, making planning and the ride itself easier.
Display Bosch Purion 200
Control unit with compact colour display and fully networked Smart System. The Purion 200 offers a range of features for an even better ride. For example, in addition to basic functions such as switching the e-bike on and off and lighting, you can also activate the smart push assistant with the Purion 200's buttons to make pushing your e-bike while walking easier. At the touch of a button, you can change the display in seconds and easily select the information that's important to you at the time: for example, keep track of the remaining range, see how far you've gone or check your pedalling frequency.
The brand has been around since 1970. Corratec GmbH represents a combination of German craftsmanship, engineering precision and cycling passion. From racing MTBs to high-performance e-bikes with technology like the Shadow Edge Tube, Fusion Tube and ABS Pro, every e-bike is the result of precision work and strict quality. Thanks to manufacturing in Europe, it offers not only cutting-edge technology but also an environmentally responsible approach. The brand is true to the philosophy of „Passion of Cycling“ – the best bikes have been focused on innovation, tradition and quality from the very beginning. CORRATEC e-bikes are world leaders in stability, comfort and safety.
Contact: iko Sportartikel Handels GmbH, Kufsteiner Strasse 72, 83064 Raubling, Germany, e-mail: info@corratec.com, phone: +49 8035 87070, web: www.corratec.com
Parameters
General
| Model year | 2026 |
| Weight incl. battery | 26,5 kg |
| Brand | Corratec |
| Colour | Black-White |
| Load capacity | 140 kg |
Motor
| Engine manufacturer | Bosch |
| Engine type | Bosch Performance Line CX Gen. 5 - Smart System |
| Torque | 85 Nm |
| Centre engine | Yes |
Battery
| Battery capacity | 800 - 899 Wh |
| Precise capacity | 800 Wh |
Transmission
| Sorting | SRAM SX Eagle Single Click |
| Cassette | SRAM Eagle PG-1230, 11-50T |
| Shifter | Sram SX Eagle, 12 speeds |
Components
| Saddle | Selle Italia X3 XP BOOST Superflow |
| Saddlebag | Kindshock 900i, 30.9 mm |
| Handlebars | ALLOY, 35.0, 800mm, 9° Backsweep, 20mm Rise |
| Extender | ALLOY, 35.0, 35mm, 0° |
| Coats | Continental Kryptotal 60-622, Continental Kryptotal 65-584 |
Brakes
| Rear brakes | Tektro HD M535 4-piston, 203 mm |
| Front brakes | Tektro HD M535 4-piston, 203 mm |
Suspension
| Shocks | ROCK SHOX DELUXE SELECT+ RT |
| Front fork | FS Psylo Silver RC 29“ 15x110mm, 160mm |
