RAYMON Vamok Comp
All-suspension mountain e-bike with a powerful Bosch Performance Line CX motor and 800 Wh battery. 160 mm of travel, mullet wheels and RockShox premium suspension make it capable of technical climbs and descents. Ideal for trail, all-mountain and challenging terrain.
Need help?
% Discount on purchase
Bosch Performance Line CX 5.gen
100 Nm
800 Wh
12 speeds
29"; 27,5"
160 mm
RockShox Deluxe Select, air, 205x65 mm
Rear air shock with smooth operation and easy adjustment. Features an air spring for responsive response even over small bumps and adjustable rebound for better control. Thanks to its design, it increases comfort and traction on a variety of terrain for everyday riding and excursions.
Shimano Deore shifting
The Shimano Deore RD-M6100 Shadow Plus is a 12-speed derailleur that delivers precise, quiet and reliable gear changes, even in challenging terrain. Shadow Plus technology increases chain stability, reduces chain chatter and contributes to smooth drive operation.
RAYMON Vamok Comp versatile e-bike for demanding riders
An all-suspension mountain e-bike designed for demanding riders looking for performance, control and fun off-road. Combining rugged construction, quality components and a cutting-edge drivetrain, you'll enjoy trail rides and technical descents without compromise.
Powerful drive and long range
The Vamok Comp is equipped with a powerful Bosch Performance Line CX (5th generation) mid-motor with a maximum torque of 100 Nm, providing strong assistance even on steep climbs. The integrated Bosch PowerTube 800 Wh battery offers a long range - ideal for all-day trips in hilly terrain.
Superior suspension and handling
It has full suspension with 160mm of travel front and rear thanks to the RockShox Psylo Silver RC air fork and RockShox Deluxe Select shock, delivering smooth and controlled suspension even on challenging trails. The Mullet wheel configuration (29″ front and 27.5″ rear) increases stability and trail handling without sacrificing agility.
Quality components for trail and all-mountain riding
The e-bike is equipped with a 12-speed Shimano Deore groupset that provides a wide range of gears for all types of climbs and flats. Tektro TR54 hydraulic disc brakes with 203mm discs ensure confident and reliable braking in all conditions. Schwalbe Magic Mary Performance tyres with Tubeless Ready technology offer excellent grip on the trails.
Comfortable and practical details
The Vamok Comp has an ergonomic frame geometry made from Alloy 6061 aluminium alloy, so it handles bumps and steeper passages well. The dropper seatpost allows quick adjustment of saddle height while riding, increasing control and comfort in technical sections.
Who the Raymon Vamok Comp is perfect for:
For riders who want a strong, reliable e-MTB for technical terrain
For trail, all-mountain and downhill enthusiasts
For those who appreciate the power of the Bosch CX motor and high battery capacity
For experienced riders and those who want to take their riding further
E-bike range calculator
Flat
Medium
Hills
The e-bike range is approximately
*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
Bosch Performance Line CX 5th generation engine
The 5th generation motor offers 85 Nm and a peak power of 600 W (up to 100 Nm / 750 W after update). Thanks to the magnesium housing, it is lighter (2.8 kg) and quieter. The new mounting system makes installation easier. Improved sensors measure rider inputs more accurately, ensuring a more natural power transfer. The motor has hill-start and walk assist for added comfort. Lower weight improves maneuverability and component durability. Auto mode automatically adjusts terrain assistance. Compatibility with Bosch smart systems allows tracking of ride details, making planning and the ride itself easier.
Battery Bosch PowerTube 800 Wh
Maximum energy for long rides. Designed for riders who want maximum range, high reliability, and clean design. Modern technology and full compatibility with the Bosch Smart System. It uses advanced lithium-ion cells and a sophisticated Battery Management System (BMS) that protects the battery against overheating, overcharging, deep discharge, and short circuits. Weight around 3.9 kg.
Designed to be well protected against water, mud, and mechanical damage. With a standard 4A charger, it reaches approximately 50% capacity in about 2.5 hours and a full charge in less than 7 hours. It is gentle on the cells and promotes long battery life.
Raymon is a German brand of electric bikes led by the experienced duo Susanne and Felix Puello, pioneers of full suspension e-MTBs. With an emphasis on quality, innovation and top-of-the-line Bosch, Yamaha and ZF CentriX drivetrains (made in the Czech Republic), it is quickly making a name for itself across Europe. It offers precision-built models with excellent value for money - from the lightweight Airock to the trail-ready Tarok to the versatile Trailray. We are a dedicated Raymon e-bike shop and will be happy to advise you on your choice.
Contact: RAYMON Bicycles GmbH, Rudolf-Diesel-Straße 35, 97424 Schweinfurt Germany, e-mail: info@raymon.com, phone: +49 9721 539 35 96 20, website: www.raymon-bicycles.com
Parameters
General
| Model year | 2026 |
| Weight including battery | 27 kg |
| Brand | Raymon |
| Frame size | Frame S, Frame L, Frame XL, Frame M |
Motor
| Engine manufacturer | Bosch |
| Engine type | Bosch Performance Line CX Gen. 5 - Smart System |
| Torque | 100 Nm |
| Centre engine | Yes |
Battery
| Battery capacity | 800 - 899 Wh |
| Precise capacity | 800 Wh |
| Charger | 4 A |
Transmission
| Sort by | Shimano Deore SL-M6100, Rapidfire Plus |
| Cassette | Shimano CS-M6100-12, 10-51 teeth, 12-speed |
| Shifter | Shimano Deore RD-M6100 12s Shadow Plus Design |
| Number of gears | 1x12 |
Components
| Grips | Raymon Sport, lock on |
| Saddlebag | Raymon, 34,9 mm, Dropper Post |
| Saddle | Raymon 150 VacTech |
| Handlebars | Raymon Riser 35 mm, Sweep: 9°, Rise: 20 mm |
| Extender | Raymon 35, 0°, Ahead |
| Coats | Schwalbe Magic Mary Performance, 62 – 622 |
Brakes
| Rear brakes | Tektro Gemini SL, 4-piston, hydraulic, 203 mm |
| Front brakes | Tektro Gemini SL, 4-piston, hydraulic, 203 mm |
Suspension
| Front fork | RockShox Psylo Silver RC |
| Fork travel | 160 mm |
| Shocks | RockShox Deluxe Select |
| Rear travel | 160 mm |
| Shock dimensions | 205 × 60 mm |
