RAYMON Tarok Comp
The Raymon Tarok Comp brings the revolutionary Avinox technology in a more affordable package without compromising on extreme performance. With 125Nm of torque, an FP700 battery and a durable Shimano Cues Linkglide mount, this model is the ideal companion for demanding trails and everyday mountain adventures.
Description
Avinox M2
up to 125 Nm
700 Wh
11 speeds
MX - 27,5"/29"
160 / 150 mm
Cockpit without chaos = 100% concentration
Enjoy an undisturbed ride and perfect visibility thanks to a clean cockpit with integrated cable management.
Total integration and smart technology
Tarok's slim silhouette perfectly masks the power of a full-size e-MTB thanks to precise integration. The controls are dominated by a 2" OLED display (326 ppi) with 800 nits brightness that intuitively responds to gestures even in gloves or rain. A clean cockpit without unnecessary cables is provided by the wireless Bluetooth controllers, which not only looks great but also greatly simplifies maintenance and service. Modern technology that serves your flow.
Maximum flow, zero compromise
The combination of a 64° angle and mullet setup delivers downhill confidence and cornering agility. The high stack saves your energy, while the low standover ensures maximum freedom of movement. The tuned build efficiently transfers the Avinox engine's 150Nm of torque to the terrain, so even on the steepest exits the front wheel stays nailed to the ground.
Pure performance without the frills
No gimmicks, just maximum durability. Tarok relies on standardized parts and replaceable thread inserts in carbon, making it easy to service and protecting the frame. With LinkGlide or T-Type drivetrains and Smooth Shift on top models, you get technology that lasts forever. The result? Less time in the shop and more time on the trail, thanks to bulletproof components that will hold you up even on the toughest descents.
Tarok Comp: redefining e-performance
The Raymon Tarok is not just another electric car on the market; it is an ambitious manifesto for modern e-mobility that pushes the boundaries of physics. An all-carbon frame made of high-strength HSC Carbone (combined with a rear structure made of durable AL61-T6 alloy on the Comp model) with progressive geometry hosts one of the greatest technological innovations of our time - the DJI Avinox propulsion system. The Tarok was designed from the ground up to blur the distinction between a powerful "full-power" electric bike and the nimbleness of lightweight e-bikes. The result is an incredibly agile machine that dominates technical exits and the steepest descents, backed by a minimalist design and uncompromising performance.
Available power without limits
The Tarok Comp is designed for riders looking for brutal power and modern technology in a package with the best value for money. At the heart of the bike is the Avinox M2 engine, which offers a peak power output of 1100 W and a high torque of 125 Nm. Enough power for all-day rides is provided by the proven Avinox FP700 battery with 700 Wh capacity. Control over the terrain is provided by the RockShox suspension - specifically the Psylo Silver RC fork with 160 mm travel and the Deluxe rear shock, a setup optimized for smooth operation and easy maintenance.
The bike's drivetrain uses an advanced Shimano Cues kit with Linkglide technology, which was developed specifically for the specific needs of performance e-bikes. This kit excels in extreme chain and cassette durability, ensuring smooth shifting even under the high thrust of a 125Nm motor. Safe stopping is handled by Tektro Orion M6041 four-piston hydraulic brakes with 203mm discs. The bike is built on Raymon 'mullet' braided wheels fitted with Schwalbe's bulky Nobby Nic Performance tyres, which offer a great mix of traction and low rolling resistance. A unique feature of the Avinox system on this model is also Apple's Find My network support, making it easy to locate the bike when needed.
This model is an ideal choice for bikers looking to get their first taste of the power of the Avinox ecosystem and are looking for a reliable, high-performance machine that straddles the line between trail and enduro. The Tarok Comp is designed for riders who prefer the mechanical durability and longevity of Shimano Cues components over chasing every gram, but still require technological conveniences like an integrated display with Bluetooth connectivity and a brutal engine pull to get them up every hill.
Need help choosing the right e-bike? Use our guide to choosing an e-bike, or contact us directly.
E-bike range calculator
Flat
Medium
Hills
The e-bike range is approximately
*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
Carbon fibre
E-bikes that use carbon fiber are a common choice among amateur and professional cyclists. Previously, it was mainly road e-bikes, but today you can enjoy the benefits of carbon on almost any type of e-bike. It remains an ideal choice among lovers of fast driving and off-road driving. The main advantage of e-bikes with a carbon frame is exceptional shock and vibration damping, they resist corrosion and wear very well and, compared to other materials, they excel in their low weight.
Avinox M2
The perfect balance of power and efficiency, with 110 Nm of torque (125 Nm with boost), a peak power output of 1100 W, and a lightweight design (2.65 kg). The second generation with helical gears and Dual Gear Engagement technology ensures quiet operation without knocking during descents. New bearings minimize resistance for a natural riding feel, while improved cooling ensures stability even in the heat. Integrated sensors enable adaptive power control based on cadence and riding conditions, making it the ideal, smooth workhorse for modern trail riding.
Avinox FP700 Battery
The Avinox FP700 battery, with a capacity of 700 Wh, utilizes revolutionary 4680 automotive cells for maximum current handling. It is very lightweight (3.18 kg), IP56-rated, and enables the M2S motor to achieve a full continuous power output of 1500 W. Intelligent health management guarantees 80% capacity even after 500 cycles. Powerful GaN fast charging replenishes energy to 80% in a record 1 hour and 16 minutes.
Avinox DPC100 Display
A smart 2" OLED touchscreen integrated into the frame with a high resolution of 326 ppi and 800 nits of brightness, which automatically adjusts to the surroundings. It is equipped with GPS sensors, a gyroscope, a barometer, and support for Bluetooth 5.1 and ANT+. The DPC100 model stands out with support for Apple Find My for easy bike tracking and allows you to adjust virtually all system functions directly on the screen without needing an app. It records your route, performance, and cadence in detail. Controls are complemented by wireless handlebar controls (right controller available only on select models) and a built-in 10W USB-C port for charging accessories while riding.
Raymon Lifetime Warranty
Starting with the 2025 model year, Raymon offers the RAYMON Care program, which provides a lifetime warranty on the frame for the first owner. This warranty covers structural defects in the frame, but does not apply to paint, bearings, or suspension components. Activation is subject to online registration within 90 days of purchase.
For selected e-bikes (Trailray, Tourray, Crossray, Hardray, and Select specification models from 2025), the RAYMON CarePlus program is available, which extends the warranty on the motor, controls, and battery to 3 years. For batteries, the limit is set at 800 charging cycles or a capacity drop below 70%.
The warranty is void in the event of racing or commercial use, improper tuning, or failure to have the bike serviced regularly by an authorized partner.
Raymon is a German brand of electric bikes led by the experienced duo Susanne and Felix Puello, pioneers of full suspension e-MTBs. With an emphasis on quality, innovation and top-of-the-line Bosch, Yamaha and ZF CentriX drivetrains (made in the Czech Republic), it is quickly making a name for itself across Europe. It offers precision-built models with excellent value for money - from the lightweight Airock to the trail-ready Tarok to the versatile Trailray. We are a dedicated Raymon e-bike shop and will be happy to advise you on your choice.
Contact: RAYMON Bicycles GmbH, Rudolf-Diesel-Straße 35, 97424 Schweinfurt Germany, e-mail: info@raymon.com, phone: +49 9721 539 35 96 20, website: www.raymon-bicycles.com
Parameters
General
| Model year | 2027 |
| Brand | Raymon |
| Frame size | Frame M, Frame XL, Frame S, Frame L |
| Colour | White, Black |
| Load capacity | 130 kg |
Motor
| Engine manufacturer | Avinox |
| Engine type | Avinox M2 |
| Torque | 110 Nm (Boost 125 Nm) |
| Centre engine | Yes |
| Display | Avinox DPC100 with left and right controller |
Battery
| Precise capacity | 700 Wh |
| Battery capacity | 700 - 799 Wh |
| Charger | Avinox Charger 4 A |
Transmission
| Number of gears | 1x11 |
Suspension
| Front fork | RockShox Psylo Silver RC |
| Fork travel | 160 mm |
| Shocks | RockShox Deluxe |
| Rear travel | 150 mm |
| Shock dimensions | 205 × 60 mm |
