LEADER FOX Awalon 29" lady
Women's mountain e-bikes. Awalon model with a powerful Bafang M420 engine, integrated 720 Wh battery, lightweight aluminum frame, sprung fork, disc brakes and fast 29" wheels.
- motor: BAFANG M420
- battery: LG 720 Wh
- frame size: 16,5", 18", 20"
- number of gears: 9
- display: TFT LCD 860C
- fork stroke: 100 mm
E-bike range calculator
The e-bike range is approximately
*Factors affecting total range include assist mode settings, technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
LEADER FOX Awalon 29" lady mountain e-bike.
A novelty is a fully integrated frame battery with powerful LG cells with a capacity of 720Wh / 20Ah. Another plus is the fast charger with a charging current of 3A. Thanks to which the battery charging time is significantly reduced. The e-bike is equipped with a Bafang M420 central motor with a nominal power of 250W and a maximum power of 550W. Among other things, this motor boasts a high torque, which can reach a value of up to 80 Nm and is equipped with a torsional pedal force sensor. This means that the more force the cyclist steps on, the more force the engine helps. The Bafang M420 electric motor quickly became one of the established central motor, mainly due to its high-quality workmanship. It also excels in very smooth running, great climb performance and quiet running. The system is controlled by a color LCD display and a button control located on the handlebars.
Range on a fully charged battery:
- average 120 km
- maximum up to 150 km
Color LCD display shows the functions:
- selection of 5 assistance modes
- WALK function (walking speed - use eg: when driving a bike up a steep hill)
- display of current, maximum and average speed
- kilometers traveled: single journey / total distance traveled
- day and night mode (display backlight)
- battery charge indicator
- USB port for charging the phone
Accessories:
The charger and battery are included in the package.
Are you struggling to find the perfect e-bike for you or have any other questions? Please, don't hesitate to get in touch with us as we are always happy to help.
Bafang M420 motor
The Bafang M420 central electric motor offers 250 wats of power and 80 newton meters of torque. This type of motor is equipped with a torsion (pressure) sensor, the control unit evaluates the force with which the rider steps on the pedals and regulates the motor power accordingly. It differs from its predecessor in the axis with the attachment of the handle on the millennium. The software remains the same. A gear senson can also be mounted to the motor.
LEADER FOX is one of the most popular brands of e-bikes and here at GREATEBIKE.EU we are the largest exporter of LEADER FOX electric bicycles for European market. The brand offers 40 models, from folding to urban touring to trekking. With full battery integration and the use of powerful mid and hub drives, LEADER FOX e-bikes are a great option for anyone looking for quality and design at a reasonable price. The design, preparation of production models and assembly all take place in a workshop situated in České Budějovice, in the Czech Republic
Parameters
General
| Model year | 2021 |
| Weight incl. battery | 24,8 kg |
| Brand | Leader Fox |
| Load capacity | 120 kg |
Motor
| Engine manufacturer | Bafang |
| Engine type | Bafang M400-420 |
| Torque | 80 Nm |
| Centre engine | Yes |
Battery
| Battery capacity | 700 - 799 Wh |
| Charger | 36V/3Ah |
Suspension
| Front fork | RST AERIAL,TRAVEL 100mm AIR, |
Components
| Extender | EXERACE, hliníkový, délka: 70mm |
| Rear hub | FORMULA DC-32, 2x ZAPOUZDŘENÉ LOŽISKO, HLINÍKOVÁ, RYCHLOUPÍNÁK |
| Front hub | FORMULA DC-91, 2x ZAPOUZDŘENÉ LOŽISKO, HLINÍKOVÁ, RYCHLOUPÍNÁK |
| Saddlebag | EXERACE D:31,6mm, L:350mm |
| Saddle | SELLE ROYAL ARIEL, ROYAL GEL |
| Coats | MAXXIS RECON RACE 29 x 2,25 |
Transmission
| Cassette | 11-36T |
| Number of gears | 1 x 9 |
