LEADER FOX AWALON 27,5"
The mountain e-bike features a Bafang M420 mid-motor and a fully integrated 720 Wh frame battery for a really long range. Aluminum frame, sporty design, suspension fork and other clever components ensure comfort on the trail.
Discount when buying 2 or more e-bikes:
5%
Motor
Bafang M420
Motor power
80 Nm
Battery capacity
720 Wh
Shifter
9 speed
Wheels
27,5"
Shock travel
100 mm
E-bike range calculator
The e-bike range is approximately
*Factors affecting total range include assist mode settings, technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
LEADER FOX AWALON 27,5" mountain e-bike with aluminium frame, sporty design, suspension front fork, disc brakes and 27,5" wheels. Fully integrated frame battery with powerful LG cells with a capacity of 720 Wh / 20Ah and a fast charger with a charging current of 3A . Thanks to which the battery charging time is significantly reduced.
The e-bike is equipped with a Bafang M420 center motor with a nominal power of 250W and a max power of 550W. This motor boasts, among other things, a high torque that can reach up to 80 Nm and is equipped with a torsion sensor for pedaling force. This means that the more force the cyclist pedals with, the more force the motor assists.
The Bafang M420 electric motor excels with very smooth running, above-average performance on climbs and quiet operation. The system is controlled by a colour LCD display and a push-button controller located on the handlebars.
Range on a fully charged battery:
- 120 km average
- maximum up to 150 km
Are you struggling to find the perfect e-bike for you or have any other questions? Please, don't hesitate to get in touch with us as we are always happy to help.
Bafang M420
Central motors are currently the most widely used drives in e-bikes, and although their introduction did not come until 2014, their advantages quickly gained great popularity. Central engines have almost pushed out the hub engines and are already found in almost all types of e-bikes.
Battery LG 720 Wh
High-capacity LG Li-Ion battery 720 Wh / 20 Ah. It is partially integrated into the frame of the e-bike and supplies energy to the entire system. Thanks to the central mounting, the e-bike is perfectly balanced, stable and easy to handle.
The battery is able to deliver an e-bike on a single charge up to a distance of 170 km (depending on the circumstances).
Of course, it is equipped with a BMS board (Battery Management System), which protects it from overheating, short circuit or overcharging. You can charge the battery directly on the bike carrier or it can be removed to charge it. You can fully charge a fully discharged battery in 5 hours.
Display LCD DP C190
Modern Bafang LCD display DP C190.CAN. The case is made of ABS (acrylonitrile butadiene styrene), the transparent part is made of high strength acrylic with the rigidity of tempered glass. Can be used down to -20oC. CE / IP65 water proof / ROHS certification.
Battery power 36V
Battery capacity indicator
Rated operating current 40mA
Leakage current at tripping < 1 uA
CAN BUS protocol
USB port 5V 500mA
Maximum output current 100mA
Operating temperature -20 ~ 45°C
Storage temperature -20 ~ 60°C
LEADER FOX is one of the most popular brands of e-bikes and here at GREATEBIKE.EU we are the largest exporter of LEADER FOX electric bicycles for European market. The brand offers 40 models, from folding to urban touring to trekking. With full battery integration and the use of powerful mid and hub drives, LEADER FOX e-bikes are a great option for anyone looking for quality and design at a reasonable price. The design, preparation of production models and assembly all take place in a workshop situated in České Budějovice, in the Czech Republic
Parameters
General
| Model year | 2023 |
| Weight incl. battery | 27 kg |
| Brand | Leader Fox |
| Load capacity | 120 kg |
Motor
| Engine manufacturer | Bafang |
| Engine type | Bafang M420 |
| Torque | 80 Nm |
| Centre engine | Yes |
Battery
| Battery capacity | 700 - 799 Wh |
| Charger | 42V/3A |
| Battery capacity | Extreme |
Suspension
| Front fork | Air, Stroke: 120 mm |
Components
| Saddle | Exerace |
| Handlebars | Alloy, bent:30 mm, width:740 mm |
| Coats | Maxxis Recon 27,5x2,25 |
Transmission
| Number of gears | 1x9 |
| Sort by | Sunrace, DLM903 R9, 9 speed |
| Cassette | 9 speed 11-36T |
| Shifter | Shimano Altus RD-M370-L |
Brakes
| Rear brakes | Tektro T875, hydraulic, 2 pistons |
| Front brakes | Tektro T875, hydraulic, 2 pistons |
