KELLYS Theos RS30

KELLYS Theos RS30: High-performance, long-range trail e-bike

The KELLYS Theos RS30 is an all-suspension mountain e-bike designed for demanding riders who want to tackle technical trails and longer mountain trips. This model combines modern geometry, a powerful motor and a large battery to offer stability, performance and comfort on any terrain.

Construction and frame

The Theos RS30 uses a frame made of durable 6061-T6 aluminum alloy, robotically welded in Europe and built with the Think Link® concept. Rear travel reaches 140mm, providing ample comfort and control on challenging terrain. An interesting feature is the combination of 29″ front and 27.5″ rear ("mullet") wheels, which provides stability on fast descents and agility in corners.

Engine and battery

At the heart of the bike is the PANASONIC GXM MAXXPRO mid-motor with 105 Nm of torque, which delivers smooth and powerful assistance even on steep exits. The 820 Wh battery allows for long day trips without having to worry about running out of power. The positioning of the battery in the frame also lowers the bike's centre of gravity and improves handling.

Components and suspension

The Theos RS30 is equipped with quality components suitable for demanding trail conditions:

• Air fork with sufficient travel for trail
• DebonAir rear shock for responsive and controlled suspension
• Hydraulic disc brakes for confident stopping power
• 1×11 gears, suitably graduated for hilly and fast terrain.

For whom the RS30 is ideal

This model is designed for riders looking for a powerful trail e-bike with full suspension, a powerful motor and a high capacity battery. It's suitable for technical descents, long mountain trips and all-day trail rides where you'll appreciate stability, handling and long range.

The KELLYS Theos RS30 offers a balanced combination of performance, comfort and technology. Its powerful motor, long battery life and modern frame geometry make it the ideal choice for anyone who wants to tackle challenging trails while having a reliable partner for longer trips.

KELLYS BICYCLES s.r.o. now offers an extended warranty of 5 years. This extended warranty covers the frame of the e-bike and its claim when a manufacturing or material defect is proven to be the cause.

E-bike range calculator

Battery capacity: 500 Wh

300 Wh 600 Wh 900 Wh 1200 Wh

Rider weight: 75 kg

50 kg 80 kg 110 kg 140 kg

Assistance mode: 3

Min 2 3 4 Max

Route profile: Flat

Flat

Medium

Hills

The e-bike range is approximately

*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique

Motor Panasonic GXM MAXXPRO

MAXXPRO – a revolutionary new e-bike drive system. Designed to deliver full power without unnecessary weight. The GXM MAXXPRO motor, developed jointly by Kellys and Panasonic, has a torque of 105 Nm and weighs just 2.56 kg, with a special magnesium alloy casing. Optimized cooling and mounting. The combined motor and battery system weighs approximately 6.1 kg. Modular and modern electronics: Open architecture, over-the-air (OTA) update capability, and compatibility with various batteries via CAN bus (open system).

More information

Battery Kellys Maxxpro 820 Wh

Kellys, in cooperation with German battery manufacturer BMZ, presents a new series of batteries called Maxxpro, which excel in high energy density. Energy density is the amount of energy stored in a given amount of material, measured in Wh/kg. Carbon batteries are up to 20% lighter and offer higher capacity. The batteries weigh approximately 3.5 kg. To achieve low weight and high energy density, Kellys used an all-carbon battery body.

More information

PANASONIC GXM Center Display 501

A highly modern central display designed for e-bikes with Panasonic drives. This display provides a clear overview of all key information – from speed, range, and assistance level to navigation and connection to a smart app via Bluetooth® 5.0. Enables stable and fast connection to smartphones and Panasonic apps, including firmware updates and ride data transfer. Intuitive navigation. The display provides information on speed, range, battery status, assistance mode, and other bike functions. The display is resistant to water, dust, and vibrations, and is readable even in direct sunlight.

GXM Remote 501

A modern control unit located on the handlebars, designed for intuitive control of e-bikes equipped with Panasonic GX series drives. The controller allows quick and safe switching between assistance levels and control of additional functions. Designed to be easily accessible with your thumb, minimizing the need to take your attention off driving. Ergonomic design. Intuitive button layout. High durability. Fast response and precise control. Seamless integration with Panasonic GX and GXM series motors and displays.

Designing and manufacturing e-bikes is not just about putting mechanical components together. It's more than that. The purpose for which an e-bike is created is important, because it has a unique purpose in each person's life. This mission gives every KELLYS e-bike its reason for being. Thanks to modern technology, skilled designers and the best materials, the Kellys brand has some of the highest quality e-bikes.

We are specialists in KELLYS electric bikes. We offer full suspension and fixed mountain bikes, touring bikes, men's and women's electric bikes with an excellent price / performance ratio.
