APACHE Rio Grande MX1

Apache Rio Grande MX1 - for the trip and the city

The Apache Rio Grande MX1 is a versatile touring/urban e-bike that combines a lightweight, low-entry frame, powerful motor and quality equipment for a comfortable ride on and off the trails. An aluminum frame with a rigid rear structure provides excellent power transfer and confident handling, while the SR Suntour X1 Air fork with 100mm of travel dampens bumps and provides a smooth ride even on rocky or gravel roads.

The 48V Bafang M510 mid-motor provides smooth power delivery and plenty of power even when going uphill. Power is supplied by an integrated 720 Wh Samsung battery, ensuring long range and reliable performance even on day trips. The Bafang DP.C010.CN display provides clear control and parameter monitoring.

The drivetrain consists of an 11-speed Shimano Cues drivetrain that combines precise shifting with a durable design suitable for electric bikes. The Shimano RD-U6000 derailleur combined with an 11-45 tooth cassette provides a wide gear range for smooth riding on flats and hills.

Shimano MT201 hydraulic disc brakes with 180/160 mm discs ensure confident braking performance in any situation. Rider comfort is ensured by ergonomic Velo grips, a comfortable Selle Royal Vivo saddle and a sturdy Apache seatpost.

The 27.5" diameter wheels are fitted with KT Thru Axle hubs and Kenda Small Block 8 27.5 x 2.1" tyres, combining speed and reliable grip. Its versatility makes the Rio Grande MX1 a great choice for cyclists looking for a reliable e-bike with high range, easy handling and quality equipment for all-round use.

Need help choosing the right e-bike for you? Take advantage of our guide to choosing an e-bike or contact us directly.

E-bike range calculator

Battery capacity: 500 Wh

300 Wh 600 Wh 900 Wh 1200 Wh

Rider weight: 75 kg

50 kg 80 kg 110 kg 140 kg

Assistance mode: 3

Min 2 3 4 Max

Route profile: Flat

Flat

Medium

Hills

The e-bike range is approximately

*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique

BAFANG M510

The new M510 mid-motor is designed especially for high-performance e-bikes. Torque is essential for dynamic riding, up to 95 Nm in this motor, which can estimate the right amount of power according to the rider's pedalling force and dial in the appropriate assistance.

The M510 is half a kilogram lighter and weighs only 2.9 kg. The weight saving is the result of several design changes, the main one being the new magnesium housing.

The M510 mid-engine is a revolutionary upgrade to the powerful eMTB engine. Maximum cadence support is extended up to 120 rpm.

More information

Battery Samsung 720 Wh

High-capacity Samsung Li-Ion battery 720 Wh / 20 Ah. It is partially integrated into the frame of the e-bike and supplies energy to the entire system. Thanks to the central mounting, the e-bike is perfectly balanced, stable and easy to handle.

The battery is able to deliver an e-bike on a single charge up to a distance of 170 km (depending on the circumstances).

Of course, it is equipped with a BMS board (Battery Management System), which protects it from overheating, short circuit or overcharging. You can charge the battery directly on the bike carrier or it can be removed to charge it. You can fully charge a fully discharged battery in 5 hours.

We are specialists and we have a complete range of medium- and high-class e-bikes from the Czech brand APACHE BICYCLES. With each APACHE e-bike we offer a premium frame warranty, the first year of after-sales service for free, and perfect diagnostics for all drive technologies used. We are the main repair shop partner for APACHE BICYCLES. APACHE has a wide range of e-bikes for various uses, with several possible motor types - Bosch, Bafang and AP Silent. We also offer rebuilding and installation of hub and central sets and drives of the Apache Power System brand, including batteries and accessories.
