APACHE Hawk MX1
Mountain e-bike with Bafang M510 motor, Samsung 720 Wh battery, SR Suntour X1 Air 120 mm air fork and reliable 11-speed Shimano Cues.
Authorized Dealer
Discount on 2 or more e-bikes
Need help?
Bafang M510
95 Nm
720 Wh
11 speeds
29"
120 mm (front)
Elegant internal cable routing
Internal cable and hose routing through the frame head tube ensures a clean design, hose protection and smooth operation of all components.
Telescopic seatpost RST
Telescopic seatpost allows quick and comfortable saddle height adjustment directly from the handlebars, providing better control and comfort when riding off-road.
Apache Hawk MX1 - comfort and sport
The Apache Hawk MX1 is a versatile mountain e-bike with a solid aluminium construction, modern geometry and features that combine comfort and performance. The SR Suntour X1 Air fork with 120 mm travel offers reliable suspension and responsive handling, ideal for a combination of trail and off-road sport riding.
The Bafang M510 mid-motor with 95Nm of torque provides plenty of power for steep climbs and fast riding. It draws power from an integrated 720 Wh Samsung battery for long range. All data and assistance modes can be conveniently monitored on the Bafang DP.C010.CN display.
The drivetrain is equipped with an 11-speed Shimano Cues 11-45 tooth cassette, Bafang 38 tooth cranks and a durable KMC e-Glide chain. This combination delivers reliable and smooth shifting that can handle higher loads on hills.
Safe braking is provided by Shimano MT201/200 hydraulic disc brakes with 180 mm discs. Riding comfort is complemented by Apache handlebars with a width of 760 mm, a short aluminium stem, Velo grips and a Selle Royal Vivo saddle. There's also an RST telescopic seatpost with 150 mm of travel for better control on descents.
The 29" wheels are built on solid Al double-wall rims with KT Thru Axle hubs and shod in Kenda Troodon 29 x 2.4" tyres for grip and stability on a variety of surfaces.
The Apache Hawk MX1 is the ideal choice for cyclists looking for a versatile and powerful e-bike with a modern Bafang motor, long range and features aimed at both comfort and sport riding.
Need help choosing the right e-bike for you? Take advantage of our guide to choosing an e-bike or contact us directly.
E-bike range calculator
Flat
Medium
Hills
The e-bike range is approximately
*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
BAFANG M510
The new M510 mid-motor is designed especially for high-performance e-bikes. Torque is essential for dynamic riding, up to 95 Nm in this motor, which can estimate the right amount of power according to the rider's pedalling force and dial in the appropriate assistance.
The M510 is half a kilogram lighter and weighs only 2.9 kg. The weight saving is the result of several design changes, the main one being the new magnesium housing.
The M510 mid-engine is a revolutionary upgrade to the powerful eMTB engine. Maximum cadence support is extended up to 120 rpm.
Battery Samsung 720 Wh
High-capacity Samsung Li-Ion battery 720 Wh / 20 Ah. It is partially integrated into the frame of the e-bike and supplies energy to the entire system. Thanks to the central mounting, the e-bike is perfectly balanced, stable and easy to handle.
The battery is able to deliver an e-bike on a single charge up to a distance of 170 km (depending on the circumstances).
Of course, it is equipped with a BMS board (Battery Management System), which protects it from overheating, short circuit or overcharging. You can charge the battery directly on the bike carrier or it can be removed to charge it. You can fully charge a fully discharged battery in 5 hours.
We are specialists and we have a complete range of medium- and high-class e-bikes from the Czech brand APACHE BICYCLES. With each APACHE e-bike we offer a premium frame warranty, the first year of after-sales service for free, and perfect diagnostics for all drive technologies used. We are the main repair shop partner for APACHE BICYCLES. APACHE has a wide range of e-bikes for various uses, with several possible motor types - Bosch, Bafang and AP Silent. We also offer rebuilding and installation of hub and central sets and drives of the Apache Power System brand, including batteries and accessories.
Contact: Dajsport s.r.o., U zamecku 197, 373 82 Borsov nad Vltavou, Czech Republic, e-mail: info@apache-bike.cz, phone: +420 387 200 200, web: www.apache-bike.cz
Parameters
General
| Model year | 2026 |
| Brand | Apache |
| Frame size | Frame L, Frame M |
| Colour | Yellow |
| Load capacity | 120 kg |
Motor
| Engine manufacturer | Bafang |
| Engine type | Bafang M510 |
| Centre engine | Yes |
Battery
| Charger | Bafang 3.0 A |
| Battery capacity | 700 - 799 Wh |
| Precise capacity | 720 Wh |
Transmission
| Sorting | Shimano Cues LinkGlide |
| Cassette | Shimano CS-LG400-11 CUES, 11-45T |
| Shifter | Shimano Cues |
| Number of gears | 1x11 |
Components
| Saddlebag | RST Dropper Post |
| Grips | Velo |
| Saddle | Selle Royal Vivo |
| Handlebars | Spec Soil 31,8 x 760 mm |
| Extender | Spec Stage 31,8 x 60 mm / Spec Stage 31,8 x 75 mm / Spec Stage 31,8 x 90 mm |
| Coats | Kenda |
Brakes
| Rear brakes | Shimano BR-MT200, hydraulic , 180 mm |
| Front brakes | Shimano BR-MT200, hydraulic disc, 180mm |
Suspension
| Front fork | Suntour X1 AIR |
