AMFLOW PX carbon
The new generation of powerful e-MTBs. Pushing the boundaries between lightness, performance and technology. With a carbon frame, Avinox M2S motor (150 Nm) and 700 Wh battery, it offers top performance and light weight. Adjustable geometry (up to 40 combinations) and FOX suspension ensure maximum control and versatility.
Need help?
% Discount on purchase
Avinox M2S
up to 150 Nm
700 Wh
12 speeds
29"
160/150 mm
Smart suspension system
The suspension system uses an advanced four-pin suspension that dramatically increases pedaling efficiency. The bike is also highly flexible: thanks to integrated flip chips, you can easily use both 29" and 27.5" rear wheels without changing the frame geometry and centre of gravity.
Lightning charging
The system supports GaN 3x fast charging (12A/508W), which will charge the battery from 0% to 75% in just approximately 96 minutes. The Intelligent Battery Health function actively monitors and manages the battery's health to extend its life: it guarantees 80% of its original capacity is maintained after 500 full cycles.
Smart offline navigation
The Avinox Ride app is compatible with third-party route imports and can convert historical routes to route files (GPX/FIT/TCX formats), allowing one-click synchronization and management of ride data. Once the control display receives the data, it can navigate independently without a phone connection and provide real-time directions and route deviation alerts.
AMFLOW PX Carbon - Lightweight, brutally powerful and highly customizable trail/all-mountain e-MTB
The Amflow PX Carbon is one of the most anticipated e-MTB models of 2027. This full carbon full-suspension bike with 160mm front and 150mm rear travel delivers a revolutionary combination of extreme power, light weight and unprecedented adaptability. Featuring the new DJI Avinox M2S engine and an ultra-lightweight frame (only 2.4 kg), the PX Carbon is one of the lightest full-power e-bikes on the market - total weight starts from around 20.6 kg.
Main specifications and features
- Motor: DJI Avinox M2S Nominal torque 130 Nm, up to 150 Nm in Boost mode. The motor is compact (2.59-2.65 kg), extremely smooth, quiet and provides a very natural ride feel thanks to advanced sensors and algorithms.
- Battery: integrated Avinox 700 Wh (energy density 220 Wh/kg, weight only 3.18 kg). Extremely fast charging (3x faster than standard) - from 0 to 80% in approx. 1 hour 16 minutes, full charge in approx. 1 hour 47 minutes. The battery is not removable, but thanks to fast charging this is not a problem.
- Suspension: 160 mm front / 150 mm rear (four-element system) - PX Carbon: FOX 36 Performance + FOX Float X Performance. - PX Carbon Pro: FOX 36 Factory GRIP X2 + FOX Float X Factory (Kashima).
- Frame: Full carbon, weight only 2.4 kg (size M). Up to 40 geometry settings - 5 head tube angle positions, 2 centre heights, 4 chainstay lengths. Compatible with mullet setup (29" front / 27.5" rear - standard) and full 29" wheels. Default geometry: 64.2° head angle, 78° seat angle - progressive and modern.
- PX Carbon: SRAM S1000 Eagle Transmission, Amflow XMA-30 wheels (mullet aluminum), Schwalbe Magic Mary / Albert (Gravity) tires. Integrated 2" Avinox OLED display, wireless controls on both sides, Amflow dropper seatpost (190-230 mm depending on size).
- Weight: From approx. 20.6 kg
Who is the Amflow PX Carbon for?
The Amflow PX Carbon targets demanding trail and all-mountain riders who want maximum performance without the unnecessary weight of a classic heavy e-MTB. 150Nm in Boost mode can handle the steepest climbs and technical passages, while the light weight, stiff frame and adjustable geometry ensure agile, precise and fun handling on descents and broken terrain.
Fast charging and solid range make it suitable for long day trips as well as aggressive local trails and bike parks.
The Amflow PX Carbon sets a new standard for lightweight full-power e-MTBs. It combines the raw power of the Avinox M2S generation with a modern carbon chassis that you can tailor to your riding style and terrain. Lightweight, quiet, brutally powerful and incredibly versatile.
E-bike range calculator
Flat
Medium
Hills
The e-bike range is approximately
*Factors affecting total range include technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
Avinox M2S
A high-performance motor with 130 Nm of torque (150 Nm in Boost mode), a peak power output of 1500 W, and a lightweight design (2.59 kg). The second generation features flat-wire winding for higher efficiency, quiet helical gearing, and Dual Gear Engagement technology, which eliminates rattling during descents without assistance. Internal resistance has been reduced by 41%, ensuring a natural ride even with a depleted battery. Integrated sensors enable adaptive power control based on cadence and riding conditions. Intelligent electronics ensure lightning-fast pedal response and smooth power delivery that will support you even on the most demanding terrain.
Avinox FP700 Battery
The Avinox FP700 battery, with a capacity of 700 Wh, utilizes revolutionary 4680 automotive cells for maximum current handling. It is very lightweight (3.18 kg), IP56-rated, and enables the M2S motor to achieve a full continuous power output of 1500 W. Intelligent health management guarantees 80% capacity even after 500 cycles. Powerful GaN fast charging replenishes energy to 80% in a record 1 hour and 16 minutes.
Display Avinox DP100
The display is integrated into the frame of the e-bike. It has a 2" OLED touch panel with a resolution of 326 ppi and a brightness of up to 800 nits, which automatically adjusts to the ambient lighting. It features GPS sensors, a gyroscope, a barometer and support for Bluetooth 5.1, ANT+ and LTE-Cat.1. It allows you to track your route, speed, cadence and performance with 8 GB of internal memory and synchronisation via the app. Control is provided by one or two wireless controllers on the handlebars – the left one for setting the level of assistance and the right one for scrolling through the display (the right controller is only available on selected models). The USB-C port supports fast charging with a power output of up to 65 W.
AMFLOW is an innovative e-MTB brand that combines technological know-how with a passion for mountain biking, created under the wing of DJI, which gives it technological credibility and access to advanced motor and battery solutions. It builds on the philosophy of "the motor as the heart of the bike" and focuses on combining low weight, high performance, and a natural riding feel. Thanks to DJI Avinox technology, it offers lightweight, powerful, and technically advanced e-bikes designed for riders who want real performance in the field, not just assistance.
Contact: KROSS S.A., Leszno 46, 06-300 Przasnysz, Poland, e-mail: kross@kross.pl, phone: +48 29 752 11 00, web: www.kross-europe.eu
Parameters
General
| Brand | Amflow |
| Colour | Black |
| Frame size | Frame M, Frame XL, Frame XXL, Frame L |
Motor
| Engine manufacturer | Avinox |
| Engine type | Avinox M2S |
| Centre engine | Yes |
Battery
| Charger | Avinox Charger 12 A |
Suspension
| Rear travel | 150 mm |
