TERN NBD S5i
Semi-folding city e-bike with Bosch Performance motor and belt drive
BOSCH Performance Line
65 Nm
500 Wh
Nexus-5
20"
-
The Gaia carrier is certified for a load capacity of up to 27 kg and can be used with many child car seats. It also allows vertical parking of the entire bike.
The extremely low boarding height of 39 cm means that you only need to raise your legs slightly to get on and off.
- Bosch PowerPack 500 battery for long journeys and commutes to work or school
- Extremely low center of gravity improves balance and maneuverability when riding with children in parks and narrow streets
- Suitable for riders with a height of 147-190 cm
- Proven safety and reliability: frame and fork have passed the EFBE Tri-Test for a maximum total bike weight of 140 kg
E-bike range calculator
The e-bike range is approximately
*Factors affecting total range include assist mode settings, technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
Need help choosing the right e-bike? Use our e-bike selection guide or contact us directly.
Motor Bosch Performance Line
The ideal choice for ambitious eBikers. A highly balanced, high-performance system with a maximum torque of up to 65 Nm turns the rider into an adventurer and provides the required power at any time.
Battery BOSCH Power Pack 500 Wh
Bosch Power Pack 500 Wh high-capacity battery that brings new energy to e-bikes. Thanks to its location on the frame, it does not disturb the center of gravity and the e-bike has an ideal balance. The battery is equipped with a BMS board (Battery Management System), which protects the battery from overheating, short circuit or overcharging.
- the batteries have no memory effect - it can be charged even after a short drive or while driving
- battery life is 600 - 1000 full charge cycles
- battery life in km is around 15,000 - 25,000 or 5 - 9 years
- charging time to 80% capacity is about 2 hours (4A charger)
- the weight of the battery is approx. 2.5 kg
You can buy a new (replacement) battery here.
The Tern brand has been regarded as a leader in the folding bike industry since the beginning. Tern e-bikes stand out above all for their design and their many exceptionally functional and durable technical solutions. These include the DoubleTruss frame solution and the design of the folding mechanisms.
In developing their electric bikes, Tern focused on rigid construction, ease of operation of all folding mechanisms and durability. Today, the company offers a wide range of electric bikes for different types of riders.
Parameters
General
Model year | 2023 |
Weight incl. battery | 23,4 kg (51,6 lb) |
Brand | Tern |
Colour | Červená |
Load capacity | 140 kg |
Motor
Engine manufacturer | Bosch |
Engine type | Bosch Performance |
Torque | 65 Nm |
Battery
Battery capacity | 500 - 599 Wh |
Components
Grips | Ergon |
Front hub | Disk Shimano |
Saddlebag | Odpružení Tern RideEasy, 34,9 mm, vzduchová patrona, nastavitelné předpětí |
Racks | Kinetix Comp |
Handlebars | Tern Sweep, 6061-AL |
Extender | Tern Andros |
Coats | Schwalbe Big Apple, Performance Line, 55-406, ochrana proti propíchnutí, Reflex |
Transmission
Number of gears | 1 x 5 |
Brakes
Rear brakes | Magura MT4 |
Front brakes | Magura MT4 |
