4EVER Engrave Flat
Gravel e-bike for speed and adventure with an ultra-light weight of only 15 kg! For very sporty riders. With FSA drive system, fully integrated 252 Wh battery.
Discount
when buying 2 or more e-bikes:
5%
Motor
FSA System HM 1.0
Motor power
42 Nm
Battery capacity
252 Wh
Shifter
11 speeds
Wheels
28"
Shock travel
12 mm (front)
Shimano BR-MT201 hydraulic disc brakes offer **smooth braking performance**, easy maintenance and high wear resistance.
- Hydraulic system
- Dual-piston design
- Levers with Servo Wave technology
- One Way Bleeding
- Compatible with Shimano mineral oil
Universal gravel tyre. Versatile, with balanced handling characteristics, whether on roads, unpaved paths or off-road. No matter where you ride - the Allround has no limits. The versatile profile rolls easily and vibration-free and grips safely and securely on gravel and light, dry roads.
- Tyre type: inner tube
- ETRTO marking value is 40-622
- Designed for the summer season
- Weight only 480 g
E-bike range calculator
The e-bike range is approximately
*Factors affecting total range include assist mode settings, technical condition of the e-bike, battery age, ambient temperature, headwind, and riding technique
4EVER Engrave Flat - Gravel e-bike for speed and adventure
Lightness, power and freedom every mile. 4EVER Engrave Flat is the gravel e-bike for those who want to explore the world without limits, with efficient electric propulsion and top-quality components.
Frame and construction
Minimalist and sleek **dural** frame with carbon fork for maximum rigidity and comfort. Lightweight construction with a total weight of just 15kg means the e-bike handles great even without motor assistance.
Power and performance
At the heart of this gravel e-bike beats the FSA System HM 1.0 rear motor, which provides smooth assistance with 42Nm of power. The integrated FSA 252 Wh battery is lightweight, compact and allows a range of up to 60 km - ideal for long trips or fast sprints on gravel roads.
Components and handling
Precise and reliable **Shimano Deore 1x11** shifting for maximum control in every situation. Disc brakes for confidence on off-road and tarmac. The fast **carbon fork** dampens vibrations and ensures a stable ride even in challenging conditions.
the 4EVER Engrave Flat is the gravel e-bike for those looking for lightness, performance and adventure. The ideal choice for cyclists who want to combine speed, comfort and electric support without unnecessary weight.
FSA System HM 1.0
The rear hub motor is designed by combining cutting-edge manufacturing expertise with perfect powertrain components. The hub is characterized by excellent bearing life and also highly resistant watertightness. Maximum torque 250 W and 42 Nm. FSA System HM 1.0 is equipped with an integrated torque sensor and two-speed sensors that easily adapt to different driving styles and changing conditions.
FSA System - battery 252 Wh
The battery is designed to perfectly balance low weight. Thanks to the powerful engine, 20 cells with a total capacity of 252 Wh are sufficient for a really long trip. It is specially developed BMS system protects the battery from overcharging, overheating, undervoltage or short circuit.
Compatible with FSA system motor only
Dimensions: 29.5 x 8 x 7.5 cm
Capacity: 252Wh / 7Ah
Weight only 1.4 kg
FSA Remote Button
The FSA e-bike system is complemented by an assist remote control that integrates into the top frame tube. Five assistance settings are available, including green "eco" mode and red "boost" mode, with a maximum power output of 250 W.
A dedicated app has been developed for the FSA System, available for both iOS and Android devices, which allows the rider to record driving and usage statistics, display remaining battery life and charge status, as well as full turn-by-turn GPS navigation.
The Czech Republic's traditional manufacturer 4EVER offers off-road and trekking e-bikes using Bafang and Brose motors made in Germany. E-bikes from 4EVER are excellent machines with above-standard battery capacity and apealing design. GREATEBIKE.EU offers a complete range of 4EVER e-bikes and a branded repair shop.
Parameters
General
| Model year | 2024 |
| Weight incl. battery | 15,2 kg |
| Brand | 4EVER |
| Load capacity | 120 kg |
| Colour | Titan / Hologram, Titan / Metal gold, Velvet / Metal bronze |
Motor
| Motor manufacturer | FSA |
| Engine type | FSA System HM 1.0 |
| Torque | 42 Nm |
| Centre engine | No |
Battery
| Charger | FSA 42 V / 2 A |
| Exact capacity | 252 Wh |
Suspension
| Front fork | CARBON DURABLE 12mm |
Components
| Racks | MACH1 Gravel Disc |
| Saddle | SELLE ITALIA Q-BIK |
| Saddlebag | 4EX sand blasted |
| Front hub | SHIMANO HB-RS470 12mm |
| Rear hub | FSA Gravel motor hub |
| Coats | SCHWALBE G-ONE ALLROUND 40-622 |
| Extender | 4EX sand blasted |
| Handlebars | 4EX sand blasted 720mm |
Transmission
| Sort by | Shimano Deore SL-M5100-IR, 11 r. |
| Number of gears | 1x11 |
| Shifter | Shimano Deore RD-M5120 |
| Cassette | SHIMANO CS-M7000-11, 11-42T |
Brakes
| Front brakes | Shimano BR MT201, hydraulické, 160 mm |
| Rear brakes | Shimano BR MT201, hydraulické, 160 mm |
